RS232C: 2.5mm Phone jack x 1: RS232C In/Out
RJ-45 : RJ-45 Jack x 1 (8 pin) : 10/100/1000 LAN Port
Displayport out: Displayport Jack x 1 (20 pin):
Digital RGB:TMDS (Video + Audio)
MAX: Video – 720p, 1080p, 1920 x 1080/60 Hz (WUXGA)
Audio – 48 KHz/ 2 Channel (L+R)
Supports LPCM only
USB Input:
USB2.0 TypeA x1
USB3.0 TypeA x1
Power Input: DC 12V – 19V (From OPS Slot)
Power Consumption (Max): 20 W When USB maximum loading
Power Consumption (typ.): <10 W
Power Consumption (Off): <0.5 W
Dimensions [W x H x D]: 200.0 x 30.0 x 135.0 mm
Weight: 0.6 Kg
